DMA 4500 Density Meter

Few instruments have the reputation for accuracy, durability, and reliability associated with the legendary digital density meters .Now our newest model, the DMA 4500, continues that proud tradition

Performance Driven Technology

There is no room for compromise in instruments that must be ready to perform at all times. And so it is with the DMA 4500. Derived from the advanced DMA 5000 operating platform, the DMA 4500 has the most exacting temperature control and measuring systems available in its class.

Reference oscillator built into the measuring cell

Eliminates long term drift

One adjustment at 20 �C is sufficient for the whole measuring temperature range

Faster sample throughput

All new, easy to use (really!) software

All options are menu-driven and shown on the display

You define what is calculated, displayed and printed by selecting the options right for you

On-line help available at the touch of a button

Accepts a standard IBM keyboard for comfortable operation

Conversion tables are permanently stored in memory - no need for additional programming

One button operation allows quick switching between measuring techniques

Memory for 100 measuring results

Password protection available

In-cell temperature measurement by high-precision platinum thermometer

Most accurate temperature sensor available

Traceable to several international standards

Can be adjusted and calibrated

Full range viscosity correction

For the first time, all viscosity related errors inherent to all types of oscillating U-tube density meters are automatically eliminated

Viscosity correction covers all sample viscosities

No need for viscous standards, such as sucrose standards

Measurement can be displayed with and without viscosity correction at the same time so results can be compared to older models of density meters

Built for Dependability

Like all the previous 4 place density meters , the DMA 4500 is designed to perform reliably in the most demanding environments. The spillproof front panel and housing make sure that accidental spills stay on the outside. We have even designed the DMA 4500 to minimize condensation on the instrument when the measuring temperature is below the dew point.

Every feature is specifically aimed at keeping your instrument accurate and reliable, year after year.

Designed With You in Mind ...

The DMA 4500 is the new laboratory workhorse. Built for round-the-clock operation, it will measure your samples quickly, accurately, easily ..... day after day, year after year. And everything is so easy to do. An air and water adjustment at 20 �C lets you measure at any temperature throughout the entire 0 to 90 �C range - just pick a temperature and go. There are 10 built-in measuring techniques to handle the most common applications. Use them as they are or customize them to match your specific needs .....

Collect

is an easy-to-use software program that captures readings from your meter and sends them transparently to your application or directly to a file via the RS232 interface.

Any program that allows you to manually enter data can receive data directly from Collect. Your application accepts the data as if it were manually entered from the keyboard. Collect was designed for those who simply want to turn on their computer and begin collecting data. It is extremely easy to use and will save countless hours of tedious data entry.

Applications
